קונטרולר ג’ויסטיק Minrray KBD1010 Joystick Controller PTZ

Joystick Keyboard KBD1010 Key Features：.Adopt RS485, RS422, RS232 Multiple Interface Control Signals. Support to connect up to 255 cameras.
.Support PELCO-D, PELCO-P, VISCA control protocol。
.Metal shell, Computer keyboard button design.
.Adopt Three-dimensional joystick to control the speed of the camera.
.Control camera rotation, zoom, aperture, focus, and other camera settings.
.LCD display in English and Chinese，Real-time display of the working status of the decoder and matrix.
.Key sound prompt function.
.Unique control code learning function. Customers can modify the control code instructions by themselves
.Any device on the RS485 bus can be set to a different protocol and baud rate.
.RS422 communication interface has automatic recovery function of short circuit overcurrent protection.
.The longest communication distance is up to 1200M (0.5MM twisted pair).

Specification of Joystick Keyboard KBD1010
